AMI 35-GMFD-01 Flange Yoke

Vendor: Action Machine Inc., Sku: AMI_35-GMFD-01

Product Description

Drive Shaft 3-Bolt Adapter Flange Yoke

This flange makes it easy to convert a two-piece driveshaft to one-piece U-joint style driveline while removing the need for guibo discs.



Solid aluminum flange yoke used to convert a rubber flex disc style joint to a 1350 series U-joint style joint.

    Eliminates the giubo and/or CV joint in drivetrain swaps and retrofits in custom applications such as street rods and hot rods. This flange was designed for reliability  and quality.

    Driveline Series: 1350
    U-Joint Lock Up: 3.625 Inch
    Bearing Cap Diameter: 1.188 Inch
    Pilot Type:
    Female
    Material:
    6061-T6 Aluminum
    Bolt Circle Diameter:
    4.33 Inch (110mm)
    Bolt Hole Diameter:
    0.500 Inch
    Flange Face to Centerline:
    3.25 Inch
    Weight:
    1.980 lbs
    Flange Outer Diameter:
    5.450 Inch
    Pilot Diameter:
    0.631 Inch
    Bolt Count:
    3


    Product Fitment

    Application: 6L80, 6L90, 10L80
    TR-6060 and TR-3160 manual
    Does not Fit 2004 GTO, Possibly 05-06 differential

    Notes: 35-GMFD-01 is a custom part and may fit more models than noted above. Measure pinion and output flange bolt holes and bolt circle diameter to determine if this yoke is appropriate for your build.



    0


    Compatible Parts:
    Spicer 5-1350X U-Joint

    Alternate Part Numbers:
    Sonnax T35-GMFD-01K Flange Yoke
    PTI 3502-110A Flange Yoke

    Sku: AMI_35-GMFD-01
    $220.23
    Maximum quantity available reached.

    DETAILS

    U-Joint Series:
    1350
    U-Joint Cap Size (B): 1.188"
    U-Joint Width (A): 3.625"
    Snap Ring Type: Outside Snap Ring
    Manufacturer: Action Machine Inc.
    Pilot Diameter (G): 0.631" F
    Bolt Circle (E): 4.330"
    Manufacturer Part Number: AMI_35-GMFD-01
    Flange or Swing Diameter (J):
    Bolt Hole (F): 0.500"
    Number of Bolt Holes: 3
    OEM/Alternate Part Number:

    “Outside

    .
