End Yokes
Neapco N170-4-1271-1 End Yoke
End Yoke | N170-4-1271-1
- Series: ∙ SPL 170
- Spline Count: 46
- Spline OD: 2.39”
- Bore Length: 2.750”
- Cap OD: 2.165”
- Yoke Span: 6.456"
- Hub Dia.: 2.879"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , SPL 170
- Spline Count: 46
- Spline OD: 2.39”
- Bore Length: 2.750”
- Cap OD: 2.165”
- Yoke Span: 6.456"
- Hub Dia.: 2.879"
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 2604-27 End Yoke
End Yoke | 2604-27
- Series: ∙ 7260
- Spline Count: 27
- Spline OD: 1.172”
- Bore Length: 1.062”
- Cap OD: 1.078”
- Yoke Span: 2.125” Yoke Span: 2.13"
- Hub Dia.: 1.688”
- Style: Inside Snap Ring
Rear Axle Type: | Chrysler 7.25" | Chrysler 8.25"
- U-Joint Series: , 7260
- Spline Count: 27
- Spline OD: 1.172”
- Bore Length: 1.062”
- Cap OD: 1.078”
- Yoke Span: 2.125” Yoke Span: 2.13"
- Hub Dia.: 1.688”
- Style: Inside Snap Ring
- Rear Axle Type: | Chrysler 7.25" | Chrysler 8.25"
PTI 3504-02 End Yoke
End Yoke | 3504-02
- Series: ∙ 1350
- Spline Count: 28
- Spline OD: 1.229"
- Bore Length: 1.375"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.844"
- Style: Outside Snap Ring
Rear Axle Type: | AMC 20
- U-Joint Series: , 1350
- Spline Count: 28
- Spline OD: 1.229"
- Bore Length: 1.375"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.844"
- Style: Outside Snap Ring
- Rear Axle Type: | AMC 20
Spicer 2-4-8091-1X End Yoke
End Yoke | 2-4-8091-1X
- Series: ∙ 1310
- Spline Count: 29
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.552”
- Style: Outside Snap Ring
Rear Axle Type: | Dana 30/44/50
- U-Joint Series: , 1310
- Spline Count: 29
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.552”
- Style: Outside Snap Ring
- Rear Axle Type: | Dana 30/44/50
Spicer 2-4-3331 End Yoke
End Yoke | 2-4-3331
- Series: ∙ 1310
- Spline Count: 13
- Spline OD: 0.878”
- Bore Length: 1.567”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 2.000”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 13
- Spline OD: 0.878”
- Bore Length: 1.567”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 2.000”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 140-4-11-1 End Yoke
End Yoke | 140-4-11-1
- Series: ∙ SPL 140
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.745”
- Cap OD: 1.937"
- Yoke Span: 5.457”
- Hub Dia.: 2.810”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , SPL 140
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.745”
- Cap OD: 1.937"
- Yoke Span: 5.457”
- Hub Dia.: 2.810”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 140-4-311-1X End Yoke
End Yoke | 140-4-311-1X
- Series: ∙ SPL 140
- Spline Count: 46
- Spline OD: 2.390”
- Bore Length: 2.323”
- Cap OD: 1.937"
- Yoke Span: 5.457”
- Hub Dia.: 3.250”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , SPL 140
- Spline Count: 46
- Spline OD: 2.390”
- Bore Length: 2.323”
- Cap OD: 1.937"
- Yoke Span: 5.457”
- Hub Dia.: 3.250”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 170-4-1221-1X End Yoke
End Yoke | 170-4-1221-1X
- Series: ∙ SPL 170
- Spline Count: 46
- Spline OD: 2.374”
- Bore Length: 2.406”
- Cap OD: 2.165"
- Yoke Span: 6.456"
- Hub Dia.: 3.500”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , SPL 170
- Spline Count: 46
- Spline OD: 2.374”
- Bore Length: 2.406”
- Cap OD: 2.165"
- Yoke Span: 6.456"
- Hub Dia.: 3.500”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 2-4-3801-1X End Yoke
End Yoke | 2-4-3801-1X
- Series: ∙ 1310
- Spline Count: 29
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.552”
- Style: Outside Snap Ring
Rear Axle Type: | Dana 60/70
- U-Joint Series: , 1310
- Spline Count: 29
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.552”
- Style: Outside Snap Ring
- Rear Axle Type: | Dana 60/70
Spicer 3-4-3051-1 End Yoke
End Yoke | 3-4-3051-1
- Series: ∙ 1480
- Spline Count: 10
- Spline OD: 1.972"
- Bore Length: 1.859"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.598"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1480
- Spline Count: 10
- Spline OD: 1.972"
- Bore Length: 1.859"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.598"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-3571-1 End Yoke
End Yoke | 3-4-3571-1
- Series: ∙ 1480
- Spline Count: 10
- Spline OD: 1.750"
- Bore Length: 2.000"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.350"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1480
- Spline Count: 10
- Spline OD: 1.750"
- Bore Length: 2.000"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.350"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 5-4-6321-1 End Yoke
End Yoke | 5-4-6321-1
- Series: ∙ 1610
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.125"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.750"
- Style: Half Round
Rear Axle Type:
- U-Joint Series: , 1610
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.125"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.750"
- Style: Half Round
- Rear Axle Type:
