End Yokes
Spicer 3-4-5711-1X End Yoke
End Yoke | 3-4-5711-1X
- Series: ∙ 1410
- Spline Count: 29
- Spline OD: 1.276"
- Bore Length: 1.500"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.875"
- Style: Outside Snap Ring
Rear Axle Type: | Dana 60/70
- U-Joint Series: , 1410
- Spline Count: 29
- Spline OD: 1.276"
- Bore Length: 1.500"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.875"
- Style: Outside Snap Ring
- Rear Axle Type: | Dana 60/70
Spicer 3-4-5731-1X End Yoke
End Yoke | 3-4-5731-1X
- Series: ∙ 1350
- Spline Count: 29
- Spline OD: 1.276”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.875”
- Style: Outside Snap Ring
Rear Axle Type: | Dana 60/70
- U-Joint Series: , 1350
- Spline Count: 29
- Spline OD: 1.276”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.875”
- Style: Outside Snap Ring
- Rear Axle Type: | Dana 60/70
Spicer 3-4-5761-1X End Yoke
End Yoke | 3-4-5761-1X
- Series: ∙ 1350
- Spline Count: 26
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.550”
- Style: Outside Snap Ring
Rear Axle Type: | Dana 35 | Dana 44
- U-Joint Series: , 1350
- Spline Count: 26
- Spline OD: 1.146”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.550”
- Style: Outside Snap Ring
- Rear Axle Type: | Dana 35 | Dana 44
Spicer 3-4-6211-1 End Yoke
End Yoke | 3-4-6211-1
- Series: ∙ 1350
- Spline Count: 32
- Spline OD: 1.401”
- Bore Length: 2.000”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 2.125”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 32
- Spline OD: 1.401”
- Bore Length: 2.000”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 2.125”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-6561-1 End Yoke
End Yoke | 3-4-6561-1
- Series: ∙ 1410
- Spline Count: 10
- Spline OD: 1.500"
- Bore Length: 2.000"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1410
- Spline Count: 10
- Spline OD: 1.500"
- Bore Length: 2.000"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-6631-1 End Yoke
End Yoke | 3-4-6631-1X
- Series: ∙ 1410
- Spline Count: 10
- Spline OD: 1.500”
- Bore Length: 2.000"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1410
- Spline Count: 10
- Spline OD: 1.500”
- Bore Length: 2.000"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-6901-1 End Yoke
End Yoke | 3-4-6901-1
- Series: ∙ 1480
- Spline Count: 10
- Spline OD: 1.500"
- Bore Length: 2.000"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 1.810"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1480
- Spline Count: 10
- Spline OD: 1.500"
- Bore Length: 2.000"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 1.810"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-7261-1X End Yoke
End Yoke | 3-4-7261-1X
- Series: ∙ 1480
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.750"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.562"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1480
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.750"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.562"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-4-8691-1X End Yoke
End Yoke | 3-4-8691-1X
- Series: ∙ 1350
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.156”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.938”
- Style: Outside Snap Ring
Rear Axle Type: | GM 8.50" | GM 9.25" | GM 9.50"
- U-Joint Series: , 1350
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.156”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.938”
- Style: Outside Snap Ring
- Rear Axle Type: | GM 8.50" | GM 9.25" | GM 9.50"
Spicer 4-4-4111-1X End Yoke
End Yoke | 4-4-4111-1X
- Series: ∙ 1550
- Spline Count: 34
- Spline OD: 1.774”
- Bore Length: 2.260”
- Cap OD: 1.375"
- Yoke Span: 4.969"
- Hub Dia.: 2.500”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1550
- Spline Count: 34
- Spline OD: 1.774”
- Bore Length: 2.260”
- Cap OD: 1.375"
- Yoke Span: 4.969"
- Hub Dia.: 2.500”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 5-4-4771X End Yoke
End Yoke | 5-4-4771X
- Series: ∙ 1610
- Spline Count: 10
- Spline OD: 1.962"
- Bore Length: 2.250"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.625"
- Style: Full Round
Rear Axle Type:
- U-Joint Series: , 1610
- Spline Count: 10
- Spline OD: 1.962"
- Bore Length: 2.250"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.625"
- Style: Full Round
- Rear Axle Type:
Spicer 5-4-6321-1 End Yoke
End Yoke | 5-4-6321-1
- Series: ∙ 1610
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.125"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.750"
- Style: Half Round
Rear Axle Type:
- U-Joint Series: , 1610
- Spline Count: 38
- Spline OD: 1.998"
- Bore Length: 2.125"
- Cap OD: 1.875"
- Yoke Span: 5.312"
- Hub Dia.: 2.750"
- Style: Half Round
- Rear Axle Type:
