Action Machine Inc. is a distributor of high quality driveshaft end yokes.
Use the filters below to help narrow your selection.
Free shipping on all orders over $100.00 within the USA.
If you do not see the end yoke that you are looking for please contact us for assistance.
Hours: Monday - Friday, 7:00 am to 4:30 pm EST
CONTACT US | CHAT | (574) 287-9650
End Yokes
Spicer 3-4-7261-1X End Yoke
End Yoke | 3-4-7261-1X
- Series: ∙ 1480
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.750"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.562"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1480
- Spline Count: 34
- Spline OD: 1.790"
- Bore Length: 2.750"
- Cap OD: 1.375"
- Yoke Span: 4.188"
- Hub Dia.: 2.562"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 2-4-4021X End Yoke
End Yoke | 2-4-4021X
- Series: ∙ 1310
- Spline Count: 10
- Spline OD: 1.250”
- Bore Length: 2.000”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.750”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 10
- Spline OD: 1.250”
- Bore Length: 2.000”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.750”
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3504-243 End Yoke
End Yoke | 3504-243
- Series: ∙ 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3104-242 End Yoke
End Yoke | 3104-242
- Series: ∙ 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3304-30 End Yoke
End Yoke | 3304-30
- Series: ∙ 1330
- Spline Count: 30
- Spline OD: 1.328"
- Bore Length: 1.190"
- Cap OD: 1.063"
- Yoke Span: 3.625"
- Hub Dia.: 1.739"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1330
- Spline Count: 30
- Spline OD: 1.328"
- Bore Length: 1.190"
- Cap OD: 1.063"
- Yoke Span: 3.625"
- Hub Dia.: 1.739"
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3R04-03 End Yoke
End Yoke | 3R04-03
- Series: ∙ 3R
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.150”
- Cap OD: 1.125”
- Yoke Span: 2.563”
- Hub Dia.: 2.110”
- Style: Inside Snap Ring
Rear Axle Type: | GM 8.60"
- U-Joint Series: , 3R
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.150”
- Cap OD: 1.125”
- Yoke Span: 2.563”
- Hub Dia.: 2.110”
- Style: Inside Snap Ring
- Rear Axle Type: | GM 8.60"
PTI 3304-05 End Yoke
End Yoke | 3304-05
- Series: ∙ 1330
- Spline Count: 30
- Spline OD: 1.312"
- Bore Length: 1.275"
- Cap OD: 1.063"
- Yoke Span: 3.625"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1330
- Spline Count: 30
- Spline OD: 1.312"
- Bore Length: 1.275"
- Cap OD: 1.063"
- Yoke Span: 3.625"
- Hub Dia.: 1.812"
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3504-85 End Yoke
End Yoke | 3504-85
- Series: ∙ 1350
- Spline Count: 30
- Spline OD: 1.312"
- Bore Length: 1.150"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.940"
- Style: Outside Snap Ring
Rear Axle Type: | GM 8.50" | GM 8.60"
- U-Joint Series: , 1350
- Spline Count: 30
- Spline OD: 1.312"
- Bore Length: 1.150"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.940"
- Style: Outside Snap Ring
- Rear Axle Type: | GM 8.50" | GM 8.60"
Spicer 3-4-178-1X End Yoke
End Yoke | 3-4-178-1X
- Series: ∙ 1350
- Spline Count: 10
- Spline OD: 1.375"
- Bore Length: 1.781"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.719"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 10
- Spline OD: 1.375"
- Bore Length: 1.781"
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.719"
- Style: Outside Snap Ring
- Rear Axle Type:
AAM 40089892 End Yoke (Obsolete)
End Yoke | 40089892
- Series: ∙ 3R
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.150”
- Cap OD: 1.125”
- Yoke Span: 2.563”
- Hub Dia.: 1.940”
- Style: Inside Snap Ring
Rear Axle Type: | GM 8.50" | GM 9.25"
- U-Joint Series: , 3R
- Spline Count: 30
- Spline OD: 1.312”
- Bore Length: 1.150”
- Cap OD: 1.125”
- Yoke Span: 2.563”
- Hub Dia.: 1.940”
- Style: Inside Snap Ring
- Rear Axle Type: | GM 8.50" | GM 9.25"
Neapco N2-4-JL05-1X End Yoke
End Yoke | N2-4-JL05-1X
- Series: ∙ 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.43”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.90”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.43”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.90”
- Style: Outside Snap Ring
- Rear Axle Type:
Neapco N2-4-JL02-1X End Yoke
End Yoke | N2-4-JL02-1X
- Series: ∙ 1310
- Spline Count: 28
- Spline OD: 1.496"
- Bore Length: 1.71"
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 2.000"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 28
- Spline OD: 1.496"
- Bore Length: 1.71"
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 2.000"
- Style: Outside Snap Ring
- Rear Axle Type:
