Spicer 6-4-5461X End Yoke

Vendor: Spicer/Dana, Sku: 6-4-5461X

Product Description

Driveshaft Differential End Yoke

Specifications

Brand Spicer
Series 1710
Spline Count 46
Yoke Style BP
Hub Diameter (R) 3.250"
C/L To End Hub (S) 5.688"
Type Splined Hole
Outside Yoke Dimension (E) 6.094"
Yoke Bearing Dimension (D) 1.938"
Major Diameter 2.374"
Involute Spline No
Length Thru Hole (Q) 2.625
Includes Slinger/Plug Yes
Assembly Yes
Material Steel

VMRS: 022003072

6-4-5461X diagram

Sku: 6-4-5461X
Vendor: Spicer/Dana
$185.50
Maximum quantity available reached.

DETAILS

Manufacturer: Spicer/Dana
Centerline of Joint to End of Spline (s): 5.69"
Manufacturer Part Number: 6-4-5461X
U-Joint Series: 1710
Spline Count: 46
Spline OD: 2.380"
Bore Length: 2.62"
Cap OD (B): 1.938"
Yoke Span (A): 6.094"
Hub Dia.: 3.25"
Style:
Rear Axle Type:
Joint Angle:
31
Counterbore Depth:
ø

Bearing Strap Construction Diagram

.
