Dodge 26 Spline 1310 Series
Transmission Slip Yoke | 2-3-8731X
Transmission Applications: Fits various 26 spline transmission output shafts for early Dodge cars as well as GM and Dodge trucks including 904, A833 short tail, A500, 42RH, 42RE and AX15. Also fits some Mitsubishi models.
- 1310 Series
- Spline Count: 26
- Outside Snap Ring
-
1.062"
Cap X
3.466" Span - Length: 6.000" (CL to End)
- Manufacturer: Spicer/Dana
- 1310 Series
- Spline Count: 26
- Outside Snap Ring
- 1.062" Cap X 3.466" Span
- Length: 6.000" (CL to End)
- Bolt Circle: 3.466"
- Manufacturer: Spicer/Dana
Dodge 26 Spline 1330 Series
Transmission Slip Yoke | 2-3-14311X
Transmission Applications: Fits various 26 spline transmission output shafts for early Dodge cars as well as GM and Dodge trucks including 904, A833 short tail, A500, 42RH, 42RE and AX15. Also fits some Mitsubishi models.
- 1330 Series
- Spline Count: 25/26
- Inside Snap Ring
-
1.062"
Cap X
3.875" Span - Length: 7.000" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 25/26
- Inside Snap Ring
- 1.062" Cap X 3.875" Span
- Length: 7.000" (CL to End)
- Bolt Circle: 3.875"
- Manufacturer: Spicer/Dana
Dodge 30 Spline 1330 Series
Transmission Slip Yoke | 2-3-14031X
Transmission Applications: Fits various 30 spline output shafts for Dodge transmissions including TorqueFlite 727, A833 long tail, A518, 45RFE, 46RH, 46RE, 47RH, 47RE, 545RFE, and 65RFE. Fits Doug Nash, Dodge Viper and SRT10 with the small 1.680" seal.
- 1330 Series
- Spline Count: 29/30
- Outside Snap Ring
-
1.062"
Cap X
3.625" Span - Length: 8.030" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 29/30
- Outside Snap Ring
- 1.062" Cap X 3.625" Span
- Length: 8.030" (CL to End)
- Bolt Circle: 3.625"
- Manufacturer: Spicer/Dana
Dodge 30 Spline 1350 Series
Transmission Slip Yoke | 3-3-3931X
Transmission Applications: Fits various 30 spline output shafts for Dodge transmissions including TorqueFlite 727, A833 long tail, A518, 45RFE, 46RH, 46RE, 47RH, 47RE, 545RFE, and 65RFE. Fits Doug Nash, Dodge Viper and SRT10 with the small 1.680" seal.
- 1350 Series
- Spline Count: 30
- Outside Snap Ring
-
1.188"
Cap X
3.625" U-Joint Span - Length: 6.630" (CL to End)
- Manufacturer: Spicer/Dana
- 1350 Series
- Spline Count: 30
- Outside Snap Ring
- 1.188" Cap X 3.625" U-Joint Span
- Length: 6.630" (CL to End)
- Bolt Circle: 3.625" U-Joint
- Manufacturer: Spicer/Dana
Dodge 30 Spline 1350 Series
Transmission Slip Yoke | 3-3-02231X
Transmission Applications: Fits various 30 spline output shafts for Dodge transmissions including TorqueFlite 727, A833 long tail, A518, 45RFE, 46RH, 46RE, 47RH, 47RE, 545RFE, and 65RFE. Fits Doug Nash, Dodge Viper and SRT10 with the small 1.680" seal.
- 1350 Series
- Spline Count: 29/30
- Outside Snap Ring
-
1.188"
Cap X
3.625" U-Joint Span - Length: 7.779" (CL to End)
- Manufacturer: Spicer/Dana
- 1350 Series
- Spline Count: 29/30
- Outside Snap Ring
- 1.188" Cap X 3.625" U-Joint Span
- Length: 7.779" (CL to End)
- Bolt Circle: 3.625" U-Joint
- Manufacturer: Spicer/Dana
Ford 25 Spline 1310 Series
Transmission Slip Yoke | 2-3-8431x
C3 & A4LD
- 1310 Series
- Spline Count: 25
- Outside Snap Ring
-
1.062"
Cap X
3.466" Span - Length: 6.500" (CL to End)
- Manufacturer: Spicer/Dana
- 1310 Series
- Spline Count: 25
- Outside Snap Ring
- 1.062" Cap X 3.466" Span
- Length: 6.500" (CL to End)
- Bolt Circle: 3.466"
- Manufacturer: Spicer/Dana
Ford 28 Spline 1310 Series
Transmission Slip Yoke | 2-3-4871X
Transmission Applications: Fits various 28 spline transmission output shafts including C4, AOD, AOD-E, Tremec T-5, T-10, TR-3550, Toploader and more.
- 1310 Series
- Spline Count: 28
- Outside Snap Ring
-
1.062"
Cap X
3.466" Span - Length: 6.000" (CL to End)
- Manufacturer: Spicer/Dana
- 1310 Series
- Spline Count: 28
- Outside Snap Ring
- 1.062" Cap X 3.466" Span
- Length: 6.000" (CL to End)
- Bolt Circle: 3.466"
- Manufacturer: Spicer/Dana
Ford 28 Spline 1310 Series
Transmission Slip Yoke | 2-3-8251X
Transmission Applications: Fits various 28 spline transmission output shafts including C4, AOD, AOD-E, Tremec T-5, T-10, TR-3550, Toploader and more.
- 1310 Series
- Spline Count: 28
- Outside Snap Ring
-
1.062"
Cap X
3.466" Span - Length: 6.500" (CL to End)
- Manufacturer: Spicer/Dana
- 1310 Series
- Spline Count: 28
- Outside Snap Ring
- 1.062" Cap X 3.466" Span
- Length: 6.500" (CL to End)
- Bolt Circle: 3.466"
- Manufacturer: Spicer/Dana
Ford 28 Spline 1330 Series
Transmission Slip Yoke | 2-3-14061X
Transmission Applications: Fits 28 spline transmission output shaft for Ford 4R70W automatic transmission and more.
- 1330 Series
- Spline Count: 28
- Outside Snap Ring
-
1.062"
Cap X
3.875" Span - Length: 6.630" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 28
- Outside Snap Ring
- 1.062" Cap X 3.875" Span
- Length: 6.630" (CL to End)
- Bolt Circle: 3.875"
- Manufacturer: Spicer/Dana
Ford 28 Spline 1330 Series
Transmission Slip Yoke | 2-3-5981X
Transmission Applications: Fits various 28 spline transmission output shafts including C4, AOD, AOD-E, Tremec T-5, T-10, TR-3550, Toploader and more.
- 1330 Series
- Spline Count: 28
- Outside Snap Ring
-
1.062"
Cap X
3.875" Span - Length: 5.906" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 28
- Outside Snap Ring
- 1.062" Cap X 3.875" Span
- Length: 5.906" (CL to End)
- Bolt Circle: 3.875"
- Manufacturer: Spicer/Dana
Ford 31 Spline 1330 Series
Transmission Slip Yoke | 2-3-6041X
Transmission Applications: Fits various 31 transmission output shafts including C-6, T45, FMX, Toploader, Tremec TKO-500 &TKO-600, Tremec T56 Magnum, E4OD, ZF 5 speed and more.
- 1330 Series
- Spline Count: 31
- Outside Snap Ring
-
1.062"
Cap X
3.875" Span - Length: 6.000" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 31
- Outside Snap Ring
- 1.062" Cap X 3.875" Span
- Length: 6.000" (CL to End)
- Bolt Circle: 3.875"
- Manufacturer: Spicer/Dana
Ford 31 Spline 1330 Series
Transmission Slip Yoke | 2-3-12961X
Transmission Applications: Fits various 31 transmission output shafts including C-6, T45, FMX, Toploader, Tremec TKO-500 &TKO-600, Tremec T56 Magnum, ZF 5 speed and more.
- 1330 Series
- Spline Count: 31
- Outside Snap Ring
-
1.062"
Cap X
3.875" Span - Length: 7.460" (CL to End)
- Manufacturer: Spicer/Dana
- 1330 Series
- Spline Count: 31
- Outside Snap Ring
- 1.062" Cap X 3.875" Span
- Length: 7.460" (CL to End)
- Bolt Circle: 3.875"
- Manufacturer: Spicer/Dana
