Spicer 5C-5X U-Joint

Vendor: Spicer/Dana, Sku: 5C-5X

Product Description

Universal Joint



Spicer® Wing™Series:

For Performance that begins where the pavement ends. Spicer wing bearing style driveshafts are designed for longer life, minimal maintenance, and lower operating costs.

Series Innovations Include:

• Forged cross
• Case hardening process for strength
• Sealed slip spline system
• Triple lip seal, thrust washer, and seal guard package
• Reduced maintenance
• Increased torque capacity

*



Brand Spicer
Greaseable Yes
Type Inside Snap Ring / Wing Bearing Style
OEM Mfg Mechancis
OEM Series 2C
Converts This Series
To This Series 2R
Distance Between Bolts (S1) 3.926"
Distance Between Bolts (S2) 3.926"
Wb Type (1) HWD
Wb Type (2) HWD
Pilot Diameter (C) 10.235"
Country of Origin Italy




Cross 1 Cross 2
Series Conversion: 1480 5C
Type: Outside Snap Ring (OSR) Round, Wing
Bearing Cap Diameter: 1.375 Inch N/A
Lock Up / Length:
*Snap Ring to Snap Ring
4.188 Inch
N/A
Distance Between Bolts:  (S) N/A 1.688 Inch
Pilot Diameter: (C) N/A 4.531 Inch
Grease Type: Greaseable
Snap Rings Included: Yes
Material: Steel
Type: HWT

VMRS: 024002046

Outside Snap Ring, Wing U-joint

How to Measure a Yoke

Measure across the inside of the pilot diameter
CAUTION: Make sure your spicer ruler or caliper is directly over the center of the bolt holes and pilot hole on the yoke.
Wing Yoke DiagramMeasuring a yoke

How to Measure a Wing U-Joint

  We recommend using a caliper or micrometer to most accurately measure u-joints. U-joint caps must be compressed when measuring dimension over the caps.

Wing U-joint / Outside snap ring

 (C)
Pilot Diameter
 (G)
Distance over Caps
 (S)
Distance Between Bolts
 (D) Cap Diameter

****

Sku: 5C-5X
Vendor: Spicer/Dana
$197.17
Maximum quantity available reached.

DETAILS

OEM Series:
1480 X 5C
Manufacturer: Spicer/Dana
Greasable: Greasable
Snap Ring Type: Wing and Outside Snap Ring HWT
Manufacturer Part Number: 5C-5X
Bearing Cap Diameter: 1.375" X 1.688"
Lock Up: 4.188" X 4.531"
OEM/Alternate Part Number:
23913248772
.
