Spicer 5-788X U-Joint

Vendor: Spicer/Dana, Sku: 5-788X

Product Description

Driveshaft Universal Joint
Conversion: 7260 & 1310

Cold-forged from high-quality steel, Spicer Life Series® (SPL®) universal joints deliver the strength and durability that today’s performance vehicles demand.

Non-greaseable u-joint (pre-lubricated for the life of the part)
 • For optimal friction reduction and higher temperature resistance
Synthetic thrust washer
 • Eliminates friction and end galling
 • Prevents the heat that breaks down grease
Multi-lip seal
 • Keeps grease in—and contaminants out
 • Offers maximum retention in a wider range of environments


Cross 1 Cross 2
Series Conversion: 7260 1310
Type: Inside Snap Ring (ISR) Outside Snap Ring (OSR)
Bearing Cap Diameter: 1.078 Inch
1.062 Inch
Lock Up / Length:
*Snap Ring to Snap Ring
2.125 Inch
3.219 Inch
Grease Type: None
Snap Rings Included: Yes
Material: Steel
Package: Each / Qty 1

VMRS: 024002046

Sku: 5-788X
Vendor: Spicer/Dana
$24.88
Maximum quantity available reached.

DETAILS

OEM Series:
1310 X 7260
Manufacturer: Spicer/Dana
Greasable: Non-Greasable
Snap Ring Type: Inside and Outside Snap Ring
Manufacturer Part Number: 5-788X
Bearing Cap Diameter: 1.062" X 1.078"
Lock Up: 2.125" X 3.219"
OEM/Alternate Part Number:
023913126230
.
