Spicer 5-3-2261KX Slip Yoke

Vendor: Spicer/Dana, Sku: 5-3-2261KX

Product Description

Mid Drive Shaft Slip Yoke

Series: 1610
U-Joint Width: 5.312 Inch
U-Joint Cap Diameter: 1.875 Inch
Center Line to End of Spline: 10.812 Inch
Center Line to Face of Plug: 3.188 Inch
Spline Outside Diameter: 2.000 Inch
Spline Count: 16
Greasable: Yes
Joint Angle: 35.0 Degree
Material: Steel

VMRS: 024002038


Compatible Parts:
Spicer 5-86-68 Slip Yoke Dust Cap
0610-B Lube Fitting


Sku: 5-3-2261KX
Vendor: Spicer/Dana
$224.79
