Spicer 5-1500X U-Joint

Vendor: Spicer/Dana, Sku: 5-1500X

Product Description

Driveshaft Universal Joint

Spicer 10® Series U-Joints, from the Most Trusted Name in Drivelines.
Spicer 10® Series u-joints are the standard for premium performance in the driveshaft market. Spicer products are manufactured using statistically controlled processes to ensure you get the same high-quality part every time.

Bearing Cups
Heat-treated for strength; precision ground and case-hardened for durability

Seal and Bearings
The process of precision grinding the seal and bearing surfaces helps to improve the life of the seal and bearing.

Journal Cross
Forged with high-quality steel, precision heat-treating and case-hardening to very specific levels, ensuring optimal and consistent strength and durability.

Type: Inside Snap Ring Style (ISR)
Bearing Cap Diameter: 0.787 Inch (20 mm) (D)
Lock Up / Length:
*Snap Ring to Snap Ring
1.496 Inch (38 mm) (G)
Grease Type: Non-Greasable
Snap Rings Included: Yes
Material: Steel & Rubber
Package: Each / Qty 1
Series: Toyota

VMRS: 024002046

U-joint Diagram


inside snap ring
Interchange
Year Make / Model Location
1969 - 1979 Toyota / Corolla Rear Driveshaft at Transmission - RWD
Rear Driveshaft at Rear Axle - RWD
1981 - 1984 Toyota / Starlet Rear Driveshaft at Transmission - RWD
Rear Driveshaft at Rear Axle - RWD
1970 - 1973 Nissan / B110 Rear Driveshaft at Transmission - RWD
Rear Driveshaft at Rear Axle - RWD


More Product Information:


Alternate Part:
Neapco 1-0028 U-Joint
Sku: 5-1500X
Vendor: Spicer/Dana
$27.55
Maximum quantity available reached.

DETAILS

OEM Series:
Toyota
Manufacturer: Spicer/Dana
Greasable: Non-Greasable
Snap Ring Type: Inside Snap Ring
Manufacturer Part Number: 5-1500X
Bearing Cap Diameter: 0.886"
Lock Up: 1.482"
OEM/Alternate Part Number:
023913126469
.
