Spicer 2010948 Companion Flange

Vendor: Spicer/Dana, Sku: 2010948

Product Description

Drive Shaft Companion / Pinion Flange

Differential Companion Flange 29 Spline with Male Pilot 1350 Series Builder Axle Compatible


The differential end yoke / pinion yoke transfers the power from the driveshaft to the pinion through a u-joint at the end of the driveshaft. This allows the driveshaft to spin while the rear differential travels up and down with the suspension.




t

*



End/Pinion Yoke Specifications

Series: 1350
Major Diameter: 1.325 Inch
Spline Count: 29
Involute Spline: No
Pilot Diameter: 2.000 Inch Male
Bolt Circle Diameter: 4.25 Inch
Bolt Hole Diameter: M12-1.75 Inch T
Number of Holes: 8
Ground Hub Diameter: 1.875 Inch
Length Thru Hole: 1.5 Inch
Flange Face to End of Hub: 1.955 Inch
Companion Flange Assembly: Yes
Material: Steel
Differential Models : Dana 60/70
VMRS: 024002040


How to Measure a Driveshaft Slip Yoke.

Application

Ford, F-100 Dana 60
Ford, F-250 Dana 60
Ford, F-350
Dana 70
Dodge
Dana 60
Dodge
Dana 70
Jeep, Wagoneer Dana 60
Chevrolet Dana 60
Chevrolet  Dana 70
GMC Dana 60
Plymouth Dana 60


****


This part is compatible with:
68055243 Bolts (4 Required)

For assistance measuring your end yoke/pinion yoke you can use our:
End Yoke Measuring Guide

If you have any questions we are here to help
CONTACT US |  CHAT | (574) 287-9650

Sku: 2010948
Vendor: Spicer/Dana
$60.76
