Spicer 2-2-2029 Flange Yoke
Flange Yoke | 2-2-2029
- Series: 1310
- Pilot Dia.: 1.964" M
- Outside Snap Ring
- U-joint: 1.063" X 3.219"
- Bolt Circle: 3.740"
- Manufacturer: Spicer/Dana
- Series: 1310
- Pilot Dia.: 1.964" M
- Outside Snap Ring
- Cap: 1.063" Width: 3.219"
- Bolt Circle: 3.740"
- Manufacturer: Spicer/Dana
Spicer 2-2-1799 Flange Yoke
Flange Yoke | 2-2-1799
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- U-joint: 1.063" X 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- Cap: 1.063" Width: 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
Spicer 2-2-1609 Flange Yoke
Flange Yoke | 2-2-1609
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- U-joint: 1.063" X 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- Cap: 1.063" Width: 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
Spicer 2-2-1519 Flange Yoke
Flange Yoke | 2-2-1519
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- U-joint: 1.063" X 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
- Series: 1310
- Pilot Dia.: 2.559" M
- Outside Snap Ring
- Cap: 1.063" Width: 3.219"
- Bolt Circle: 3.346"
- Manufacturer: Spicer/Dana
Spicer 2-2-1209 Flange Yoke
Flange Yoke | 2-2-1209
- Series: 1330
- Pilot Dia.: 2.953" F
- Outside Snap Ring
- U-joint: 1.063" X 3.625"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
- Series: 1330
- Pilot Dia.: 2.953" F
- Outside Snap Ring
- Cap: 1.063" Width: 3.625"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
Spicer 2-2-01474 Flange Yoke
Flange Yoke | 2-2-01474
- Series: 1330
- Pilot Dia.: 2.436" F
- Outside Snap Ring
- U-joint: 1.063" X 3.625"
- Bolt Circle: 4.271"
- Manufacturer: Spicer/Dana
- Series: 1330
- Pilot Dia.: 2.436" F
- Outside Snap Ring
- Cap: 1.063" Width: 3.625"
- Bolt Circle: 4.271"
- Manufacturer: Spicer/Dana
Spicer 3-4-14591-1 End Yoke
End Yoke | 3-4-14591-1
- Series: ∙ 1410
- Spline Count: 29
- Spline OD: 1.276"
- Bore Length: 1.500"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.810"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1410
- Spline Count: 29
- Spline OD: 1.276"
- Bore Length: 1.500"
- Cap OD: 1.188"
- Yoke Span: 4.188"
- Hub Dia.: 1.810"
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 2-4-1921 End Yoke (Obsolete)
End Yoke | 2-4-1921
- Series: ∙ 1310
- Spline Count: 10
- Spline OD: 1.172”
- Bore Length: 1.438”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.250”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 10
- Spline OD: 1.172”
- Bore Length: 1.438”
- Cap OD: 1.063"
- Yoke Span: 3.22"
- Hub Dia.: 1.250”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 4-2-679 Flange Yoke
Flange Yoke | 4-2-679
- Series: 1550
- Pilot Dia.: 3.75" M
- Outside Snap Ring
- U-joint: 1.375" X 4.969"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
- Series: 1550
- Pilot Dia.: 3.75" M
- Outside Snap Ring
- Cap: 1.375" Width: 4.969"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
Spicer 3-2-809 Flange Yoke
Flange Yoke | 3-2-809
- Series: 1350
- Pilot Dia.: 2.750" M
- Outside Snap Ring
- U-joint: 1.188" X 3.625"
- Bolt Circle: 3.750"
- Manufacturer: Spicer/Dana
- Series: 1350
- Pilot Dia.: 2.750" M
- Outside Snap Ring
- Cap: 1.188" Width: 3.625"
- Bolt Circle: 3.750"
- Manufacturer: Spicer/Dana
Spicer 3-2-429 Flange Yoke
Flange Yoke | 3-2-429
- Series: 1410
- Pilot Dia.: 3.750" M
- Outside Snap Ring
- U-joint: 1.188" X 4.188" X 4.438"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
- Series: 1410
- Pilot Dia.: 3.750" M
- Outside Snap Ring
- Cap: 1.188" Width: 4.188" Width: 4.438"
- Bolt Circle: 4.750"
- Manufacturer: Spicer/Dana
Spicer 250-2-10491 Flange Yoke
Flange Yoke | 250-2-10491
- Series: SPL 250
- Pilot Dia.: M
- Outside Snap Ring
- U-joint: 2.362" X 6.417"
- Bolt Circle: 5.906"
- Manufacturer: Spicer/Dana
- Series: SPL 250
- Pilot Dia.: M
- Outside Snap Ring
- Cap: 2.362" Width: 6.417"
- Bolt Circle: 5.906"
- Manufacturer: Spicer/Dana
