Yoke
Spicer 3-3-7001X Slip Yoke
Mid Shaft Slip Yoke | 3-3-7001X
- Series: 1410
- Spline Count: 24
- Spline Dia.: 1.587”
- Grease: Non-Greasable
- U-joint: 1.188" X 4.188"
- Length: 6.720"
- Outside Snap Ring
- Series: 1410
- Spline Count: 24
- Spline Dia.: 1.587”
- U-joint: 1.188" X 4.188"
- Length: 6.720"
- Outside Snap Ring
Neapco N2-4-JK02 End Yoke
End Yoke | N2-4-JK02
- Series: ∙ 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.880”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.880”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 3-3-6061X Slip Yoke
Mid Shaft Slip Yoke | 3-3-6061X
- Series: 1480
- Spline Count: 24
- Spline Dia.: 1.564”
- Grease: Non-Greasable
- U-joint: 1.375" X 4.188"
- Length: 6.810"
- Outside Snap Ring
- Series: 1480
- Spline Count: 24
- Spline Dia.: 1.564”
- U-joint: 1.375" X 4.188"
- Length: 6.810"
- Outside Snap Ring
Neapco N3-4-JL05-1X End Yoke
End Yoke | N3-4-JL05-1X
- Series: ∙ 1350
- Spline Count: 24
- Spline OD: 1.250"
- Bore Length: 1.84”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.91"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 24
- Spline OD: 1.250"
- Bore Length: 1.84”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.91"
- Style: Outside Snap Ring
- Rear Axle Type:
Neapco N3-4-JL03-1X End Yoke
End Yoke | N3-4-JL03-1X
- Series: ∙ 1350
- Spline Count: 24
- Spline OD: 1.250"
- Bore Length: 1.67”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.87"
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 24
- Spline OD: 1.250"
- Bore Length: 1.67”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.87"
- Style: Outside Snap Ring
- Rear Axle Type:
Neapco N3-4-JK08 End Yoke
End Yoke | N3-4-JK08
- Series: ∙ 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.844”
- Style: Round
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.844”
- Style: Round
- Rear Axle Type:
PTI P3-3-7021X Slip Yoke
Mid Shaft Slip Yoke | P3-3-7021X
- Series: 1480
- Spline Count: 24
- Spline Dia.: 1.564”
- Grease: Greasable
- U-joint: 1.375" X 4.188"
- Length: 6.50"
- Outside Snap Ring
- Series: 1480
- Spline Count: 24
- Spline Dia.: 1.564”
- U-joint: 1.375" X 4.188"
- Length: 6.50"
- Outside Snap Ring
PTI 3504-243 End Yoke
End Yoke | 3504-243
- Series: ∙ 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1350
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.188"
- Yoke Span: 3.625"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
- Rear Axle Type:
PTI 3104-242 End Yoke
End Yoke | 3104-242
- Series: ∙ 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.500”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.876”
- Style: Outside Snap Ring
- Rear Axle Type:
Neapco N2-4-JL05-1X End Yoke
End Yoke | N2-4-JL05-1X
- Series: ∙ 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.43”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.90”
- Style: Outside Snap Ring
Rear Axle Type:
- U-Joint Series: , 1310
- Spline Count: 24
- Spline OD: 1.250”
- Bore Length: 1.43”
- Cap OD: 1.063"
- Yoke Span: 3.219"
- Hub Dia.: 1.90”
- Style: Outside Snap Ring
- Rear Axle Type:
Spicer 8-82-171-1 Yoke Shaft
Yoke Shaft | 8-82-171-1
Driveshaft Yoke Shaft Series: 1880 U-Joint Cap Diameter (D): 2.188 Inch U-Joint Width (E): 8.094 Inch Style: Full Round Major Spline Diameter: 4.156 Inch Centerline To End Of Spline (K): 7.219 Inch...
Spicer 8-3-431KX Slip Yoke Assembly
Yoke | 8-3-431KX
Driveshaft Slip Yoke Assembly Series: 1880 Style: Full Round Outside Yoke Dimension: 8.094 Inch Bearing Cap Diameter: 2.188 Inch Center Line to End of Spline: 5.031 Inch Center Line to...
