Spicer 3-3-4421X Slip Yoke

Vendor: Spicer/Dana, Sku: 3-3-4421x

Product Description

Mid Drive Shaft Slip Yoke

Mid shaft slip yoke designed to be used in conjunction with a spline shaft to allow axle movement in the driveshaft.

Specifications:

Series: 1410
U-Joint Width (B): 4.188 Inch
U-Joint Cap Diameter (A): 1.188 Inch
Center Line to End of Spline (C): 5.240 Inch
Center Line to Face of Plug: 1.160 Inch
Spline Outside Diameter (E): 1.375 Inch
Spline Count (F): 16
Greasable: Yes
Joint Angle: 20.0 Degree
Material: Steel

VMRS: 024002038

Driveshaft Slip Yoke Diagram Outside Snap Ring Style

Sku: 3-3-4421x
Vendor: Spicer/Dana
$157.41
