Spicer 10025485 End Yoke

Vendor: Spicer/Dana, Sku: 10025485

Previous Product | Next Product
Product Description

Drive Shaft End Yoke / Differential Yoke


The differential end yoke / pinion yoke transfers the power from the driveshaft to the pinion through a u-joint at the end of the driveshaft. This allows the driveshaft to spin while the rear differential travels up and down with the suspension.

Forged Pinion Yokes
A premium Spicer Performance Part.

Spicer end yoke fits axle model Ford 9" with 1350 series U-Joint and other applications with similar dimensions.  28 spline. Strap Kit included.

Forged from high-quality steel and heat-treated to ensure maximum strength, Spicer pinion yokes deliver the performance and durability that you expect. Each yoke is machined to an exact tolerance, so you get a perfect fit. And with black oxide coating, these pinion yokes offer unparalleled protection against corrosion.

  • U-bolt style (Covering most popular axle models)
  • Black oxide coating (Providing added corrosion resistance)
  • Forged steel construction (Ensuring maximum strength)








t

*



End/Pinion Yoke Specifications

U-Joint Series: 1350
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.188 Inch
U-Joint Width (B): 3.625 Inch
End Yoke Length(C) :
- Center Line to End of Spline 		4.09 Inch
Hub Diameter (D): 1.812 Inch
Spline Diameter (E):
- From Farthest Point to Farthest Point 		1.218 Inch
Number of Splines (F): 28
Bore Length (G): 2.425 Inch
Rear Axle Type:
Ford 9.00 Inch

VMRS: 022003072


How to Measure a Driveshaft Slip Yoke.

Application: Ford 9.0in Axle

This end yoke fits specific early model vehicles. Confirm all dimensions before ordering.
  Ford Thunderbird, F-100, F-150, E-100 Econoline, E-200 Econoline, Fairlane, Ranchero, Galaxie, Falcon, LTD, Mustang, Bronco, Falcon, Torino, Maverick, Gran Torino, E-100 Econoline, E-100 Econoline Club Wagon, E-150 Econoline Club Wagon, E-250 Econoline, E-250 Econoline Club Wagon, Granada
Bentley Continental
Frazer Nash Continental
Lincoln Continental, Mark III
Mercury Comet,  Grand Marquis,




****

This part is compatible with:
Spicer 3-94-18X U-Bolt Kit

For assistance measuring your end yoke/pinion yoke you can use our:
End Yoke Measuring Guide
