Spicer 6-3-2671KX Slip Yoke
Mid Shaft Slip Yoke | 6-3-2671KX
- Series: 1710
- Spline Count: 16
- Spline Dia.: 2.500”
- Grease: Greasable
- U-joint: 1.938" X 6.094"
- Length: 9.594"
- Bearing Plate
- Series: 1710
- Spline Count: 16
- Spline Dia.: 2.500”
- U-joint: 1.938" X 6.094"
- Length: 9.594"
- Bearing Plate
Spicer 6-4-2381 End Yoke
End Yoke | 6-4-2381
- Series: ∙ 1710
- Spline Count: 10
- Spline OD: 1.750”
- Bore Length: 2.250”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.750”
- Style: Full Round
Rear Axle Type:
- U-Joint Series: , 1710
- Spline Count: 10
- Spline OD: 1.750”
- Bore Length: 2.250”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.750”
- Style: Full Round
- Rear Axle Type:
Spicer 6-4-4741X End Yoke
End Yoke | 6-4-4741X
- Series: ∙ 1710
- Spline Count: 10
- Spline OD: 2.000”
- Bore Length: 2.562”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.938”
- Style: Full Round
Rear Axle Type:
- U-Joint Series: , 1710
- Spline Count: 10
- Spline OD: 2.000”
- Bore Length: 2.562”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.938”
- Style: Full Round
- Rear Axle Type:
Spicer 6-4-5041X End Yoke (Obsolete)
End Yoke | 6-4-5041X
- Series: ∙ 1710
- Spline Count: 34
- Spline OD: 1.790”
- Bore Length: 2.750”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.562”
Rear Axle Type:
- U-Joint Series: , 1710
- Spline Count: 34
- Spline OD: 1.790”
- Bore Length: 2.750”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 2.562”
- Rear Axle Type:
Spicer 6-4-5461X End Yoke
End Yoke | 6-4-5461X
- Series: ∙ 1710
- Spline Count: 46
- Spline OD: 2.374”
- Bore Length: 2.625”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 3.250”
- Style: Full Round
Rear Axle Type:
- U-Joint Series: , 1710
- Spline Count: 46
- Spline OD: 2.374”
- Bore Length: 2.625”
- Cap OD: 1.938"
- Yoke Span: 6.190”
- Hub Dia.: 3.250”
- Style: Full Round
- Rear Axle Type:
Spicer 6-4-7191X End Yoke
End Yoke | 6-4-7191X
- Series: ∙ 1710
- Spline Count: 36
- Spline OD: 2.364”
- Bore Length: 2.688”
- Cap OD: 1.938”
- Yoke Span: 6.190”
- Hub Dia.: 3.000”
Rear Axle Type:
- U-Joint Series: , 1710
- Spline Count: 36
- Spline OD: 2.364”
- Bore Length: 2.688”
- Cap OD: 1.938”
- Yoke Span: 6.190”
- Hub Dia.: 3.000”
- Rear Axle Type:
Spicer 6-82-1341-4 Yoke Shaft
Yoke Shaft | 6-82-1341-4
Driveshaft Yoke Shaft Specifications Series: 1710 U-Joint Cap Diameter (D): 1.938 Inch U-Joint Width (E): 6.094 Inch Major Spline Diameter: 2.500 Inch Centerline To End Of Spline (K): 14.000 Inch Spline Length...
Spicer 5018823 U-Joint Strap Kit (Obsolete)
Hardware | 5018823
- Strap Kit
- Series: 1710 / 1760 / 1810
- CL-CL Bolt Holes: 2.81"
- Qty: 2 Straps / 4 Bolts
- Fits Cap Dia.: 1.94"
- Thread Size: 0.50"-20
- Strap Kit
- Series: 1710 / 1760 / 1810
- CL-CL Bolt Holes: 2.81"
- Qty: 2 Straps / 4 Bolts
- Fits Cap Dia.: 1.94"
- Thread Size: 0.50"-20
Spicer 6-82-1341-2 Yoke Shaft
Yoke Shaft | 6-82-1341-2
Driveshaft Yoke Shaft Specifications Series: 1710 U-Joint Cap Diameter: 1.938 Inch U-Joint Width: 6.094 Inch Major Spline Diameter: 2.500 Inch Centerline To End Of Spline: 13.375 Inch Spline Length: 4.000 Inch Angle #1...
Spicer 6-82-341 Yoke Shaft
Yoke Shaft | 6-82-341
Driveshaft Yoke Shaft Specifications Series: 1710 U-Joint Cap Diameter: 1.938 Inch U-Joint Width: 6.094 Inch Major Spline Diameter: 3.248 Inch Centerline To End Of Spline: 5.250 Inch Spline Length: 2.000 Inch Angle #1...
Spicer 6-82-1171-10 Yoke Shaft
Yoke Shaft | 6-82-1171-10
Driveshaft Yoke Shaft Specifications Series: 1710 U-Joint Cap Diameter: 1.938 Inch U-Joint Width: 6.094 Inch Major Spline Diameter: 2.500 Inch Centerline To End Of Spline: 9.656 Inch Spline Length: 3.500 Inch...
Spicer 6-82-1171-12 Yoke Shaft
Yoke Shaft | 6-82-1171-12
Driveshaft Yoke Shaft Specifications Series: 1710 U-Joint Cap Diameter: 1.938 Inch U-Joint Width: 6.094 Inch Major Spline Diameter: 2.500 Inch Centerline To End Of Spline: 10.656 Inch Spline Length: 3.500 Inch Angle...
