Stock Upgrade One Piece Driveshaft | RAM 2500 4WD Truck (2019-2024) | CCSB | Aluminum | 1555 Series | 4.6" OD

Vendor: Action Machine Inc., Sku: 4.6A1550-B_CCSB(19-24)_Dodge

Previous Product | Next Product
Product Description

Custom Driveshaft - Aluminum, 4.6 Inch OD, 1550/1555 Series Dodge Ram 2500 4x4 Truck - 2019 to 2024 - Crew Cab, Short Bed

Upgrade your OEM one piece aluminum or convert your OEM steel two piece into a one piece heavy duty 4.6 inch aluminum driveshaft.

  • Notes
  • Specs
  • Vehicle Fitment
  • Tubing

Heavy Duty 4.6 Inch Aluminum Driveshaft

This driveshaft fits 2019 to 2024 Dodge Ram 2500, 4 wheel drive trucks crew cab short bed. Use this driveshaft to upgrade your existing one piece driveshaft or to convert your two piece driveshaft into a heavy duty one piece.

Dodge Ram driveshafts are notorious for driveshaft vibrations and component failures. Countless customers complain of their OEM two piece shaft having repeated and expensive carrier bearing failures. Our Aluminum eliminates the carrier bearing for a stronger, more reliable driveshaft.

This driveshaft is heavy duty from end to end. We use only the highest quality 1550/1555 universal joints from top brands such as Spicer or Neapco. The Aluminum tubing is 4.6 inch OD Arconic premium aluminum seamless material that is 1/8 inch thick -- rated for over 7,000 ft/lbs of torque! It will handle even the heaviest towing loads. Most of the OEM one piece aluminum shafts are only 0.083 inch thick. Some Rams have the smaller 1415 or 1485 u-joint but you can upsize to this 1555 shaft without an issue since the transfer case yoke and flange bolt pattern are the same on the Ram 4x4 trucks. The upsized driveshaft will last longer due to the bigger u-joint.

The driveshaft comes fully assembled, balanced and ready to bolt in. Installation is as simple as sliding in the transfer case yoke and bolting up the flange. It is not common but it is always a good idea to check for clearance issues with the carrier bearing cross member to ensure that the cross member does not need to be removed.

This is a 100% new 4.6 inch aluminum driveshaft including a new transfer case slip yoke, new driveshaft and new flange. This is an all new direct replacement driveshaft. All you have to do is remove your old shaft and bolt up the new shaft.

You won't be disappointed with your Ram 4.6 inch aluminum driveshaft. Time and again customers are impressed at how well made the driveshaft is and better yet, how it helps solve vibration and carrier bearing problems - no matter if is a daily driver, over the road towing rig or pulling truck.

  • Free Ground Shipping
  • Seamless Arconic Aluminum Tubing
  • Precision Balancing
  • Premium Sealed OEM U-Joints
  • Custom Length Options
  • Lifetime Weld Warranty

.

Weld Yoke Material: Aluminum 6061-T6 Forged Yoke
Tube Material: 0.120 Inch Wall 6061-T6 Seamless
Tube Outside Diameter: 4.6 Inch OD (Measuring Guide - Tube OD)
U-Joint: Neapco 3-0155G Universal Joint
Spicer SPL70X Universal Joint
U-Joint Information:
1550 Series / Premium Non-Greasable
1-3⁄8 (1.375)" Cap x 4-31⁄32 (4.969)" Span
(Measuring Guide - U-Joint)
Driveshaft Length: 64 inches u-joint to u-joint
71.375 inches seal to flange face
Transmission Slip Yoke: 40098344
Flange Yoke: 40038047



Vehicle Fitment

Model: Dodge
Make: Ram 2500
Years: 2019-2024
Drive Type: 4WD
Cab Sizes: Crew Cab
Bed Size: Short Bed
U-Joint Series: This 1550/1555 driveshaft is an upgrade form the stock 1410 & 1480 OEM series universal joint.
Engine: 6.7 Diesel
Transmission: Automatic



Quality Aluminum Tubing vs. Thin wall Swedged Tubing

Action Machine Inc.:
Heavy Duty Tubing		 The Others:
Thin Wall Swedged Tubing

The Action Machine driveshaft is a heavy-duty driveshaft made to last. You will find cheaper Ram aluminum driveshafts on the internet but that is what they are – cheaper in price and quality.

AMI aluminum vs Swedged driveshaft

When you see other aluminum driveshafts with tubing that is bigger in the middle and smaller at the ends, that is a thin wall 0.075 inch aluminum which is light duty OEM material. Our 1/8 inch thick heavy duty Arconic brand tube is made with an even wall thickness and extra straight from end to end to run vibration free and for incredible torque performance. Some driveshafts with cheaper prices have conversion u-joints that step from one u-joint size to another or greaseable u-joints. Conversion and greaseable u-joints are not as strong as the cold forged solid cross u-joints that we use and have more play. Many of the cheaper shafts have cast weld yokes at each end while ours are USA made forged weld yokes. In fact, every part of our driveshaft from end to end is USA made premium product – assembled, welded and balanced by our team here in Indiana. You can’t compare the quality, durability and life you will get from our driveshaft to other lower cost driveshafts out there.

Modified Vehicles:
This driveshaft is designed to fit stock vehicle applications, double check your driveshaft length if your truck is lifted, leveled or modified. We maybe able to make you a custom driveshaft to match your unique vehicle specifications - contact us today with your driveshaft length (measuring guide). The maximum length driveshaft that AMI can build is 89 inches seal to center of u-joint.

If you have any questions we are here to help:
CHAT | PHONE (574)287-9650 | CONTACT US

FREE GROUND SHIPPING INSIDE THE USA
(This product does not qualify for international shipping)

Sku: 4.6A1550-B_CCSB(19-24)_Dodge
Vendor: Action Machine Inc.
All driveshafts are custom built to your specification. Current lead time is 2 to 3 weeks from time of order.
$1,110.63
