PTI 3504-03 End Yoke

Vendor: PTI, Sku: 3504-03

Product Description

3504-03 End Yoke

Strap Kit: 3-70-28X





Sku: 3504-03
Vendor: PTI
$85.59
Maximum quantity available reached.

DETAILS

Manufacturer: PTI
Centerline of Joint to End of Spline (s): 3.143"
Manufacturer Part Number: 3504-03
U-Joint Series: 1350
Spline Count: 31
Spline OD: 1.343"
Bore Length: 1.262"
Cap OD (B): 1.188"
Yoke Span (A): 3.622"
Hub Dia.: 1.812"
Style: Outside Snap Ring
Rear Axle Type:
FORD 10.25"
Joint Angle:
ø
Counterbore Depth:
ø

Bearing Strap Construction Diagram

.
