PTI 3303-32 Trans Slip Yoke

Vendor: PTI, Sku: 3303-32

Product Description

PTI Drive Shaft Transmission Slip Yoke



PTI Transmission slip yoke
Transmission and Transfer Case Applications:

TH-400 Corvette Strap Style

Fits the GM transmissions with 32 spline output shaft including the Turbo 400, TH-400, Super T-10, Richmond, M22, M21, M20, Jericho, 4L85E, 4L80E  and confirm dimensions for transfer cases fitment.



Series: 1330
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.062 Inch
U-Joint Width (B): 3.625 Inch
Slip Yoke Length (C):
(Center Line to End of Spline)
4.960 Inch
Barrel Diameter (D): 1.378 Inch
Spline Diameter (E): 1.886 Inch
Number of Spline (F): 32 (31 with blind spot - see note below*)
Spline Counter Bore: Yes
Counter Bore Depth:
0.215 Inch
Counter Bore Diameter: 1.437 Inch
Vehicle Make: GM
Material: Steel

VMRS: 024002038

 * The transmission slip yoke may have one or two missing splines inside the barrel known as blind spots. Each blind spot counts as one spline in the total spline count. The blind spots do not affect the fit of the yoke on your output shaft.

Transmission Output Shaft Style

If you have a TH-400 or 4L80 confirm if you have an o-ring on the output spline of your transmission. If your transmission has an o-ring you will need a 5.5” short barrel counter bored slip yoke.

Transmission Slip yoke with and without counter bore

Some slip yokes have missing splines. To verify spline count, always count the splines on the transmission output shaft. A slip yoke counterbore is a short lead without spline in the end of the yoke.

outside snap ring slip yokeSlip Yoke

0



This part is compatible with:
Spicer 2-70-28X Strap kit
