PTI 3301-201 Companion Flange

Vendor: PTI, Sku: 3301-201

Product Description

Companion Flange - Driveshaft
Sku: 3301-201

Specifications

 Spline Count 32
Spline Diameter 1.401"
Hub Diameter 2.125"
Thru Hole 2.000"
Face to End 2.125"
Pilot Diameter 2.000"
Bolt Circle Diameter Dual
Notes 3.5 & 4.25"
Threaded or Drilled bolt holes

This companion flange can be used to build a rear CV shaft off the 203 or 205 transfer cases. This flange will mate to a 1310, 1330 or 1350 CV flange.

The mating part numbers are the 3502-21, 211631X and the 211229X.

**The 4.25" Threaded bolt holes may have to be drilled to mate with the 3502-21 threaded CV flange**

Most applications do have a threaded 4.25" driveshaft flange. So in most cases this companion flange will require the end user to drill the threaded holes out to accept the OE hardware.

Be sure to double check the ground hub measurement.
YOU MIGHT TRY USING NATIONAL SEAL NO. 473204 TO GO THE 2.125 GROUND HUB.

Sku: 3301-201
Vendor: PTI
$114.10
