Spicer 2-3-10431X Trans Slip Yoke

Vendor: Spicer/Dana, Sku: 2-3-10431X

Product Description

Spicer Drive Shaft Transmission Slip Yoke



DRIVE SHAFT TRANSMISSION SLIP YOKE
Demand genuine Spicer. Dana design, engineering, testing and manufacturing processes all work in conjunction with one another to ensure unparalleled performance that non genuine parts simply cannot deliver.

Transmission & Transfer Case Applications:

Fits the GM transmissions with 32 spline output shaft Turbo 400, TH-400, Super T-10, Richmond, M22, M21, M20, Jericho, 4L85E, 4L80E  and confirm dimensions for transfer cases fitment.



Series: 1310
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.063 Inch
U-Joint Width (B): 3.219 Inch
Slip Yoke Length (C):
(Center Line to End of Spline)
5.500 Inch
Barrel Diameter (D): 1.885 Inch
Spline Diameter (E): 1.397 Inch
Number of Spline (F): 32 (31 with blind spot - see note below*)
Spline Counter Bore: No
Vehicle Make: GM

VMRS: 024002038

 * The transmission slip yoke may have one or two missing splines inside the barrel known as blind spots. Each blind spot counts as one spline in the total spline count. The blind spots do not affect the fit of the yoke on your output shaft.

Driveshaft Slip Yoke Diagram Outside Snap Ring Style

Transmission Output Shaft Style

If you have a TH-400 or 4L80 confirm if you have an o-ring on the output spline of your transmission. If your transmission has an o-ring you will need a 5.5” short barrel counter bored slip yoke.

Transmission Slip yoke with and without counter bore

outside snap ring slip yokeDriveshaft Slip Yoke Diagram Spline Count

0


This part is compatible with:
Spicer 5-153X Universal Joint

Alternate Part Option:
Neapco N2-3-10431X Slip Yoke with Counter Bore
