PTI 3503-324 Trans Slip Yoke

Vendor: PTI, Sku: 3503-324

Product Description

Neapco Drive Shaft Transmission Slip Yoke

Part Story
Replaces 3-4-13211-1 which was a bolt-on. This part has a welch plug that can be removed to make it a bolt on. Use with strap kit 1-0020. Although we do not include a washer and bolt, we understand that the bolt should be a 1/2" 20THD.

This part is an alternate option when used with Strap kit 1-0020, for N3-3-2431X Slip Yoke.

Transmission & Transfer Case Applications:

Fits the GM transmissions with 32 spline output shaft Turbo 400, TH-400, Super T-10, Richmond, M22, M21, M20, Jericho, 4L85E, 4L80E  and confirm dimensions for transfer cases fitment.



Series: 1350
Style: Outside Snap Ring
U-Joint Cap Diameter (A): 1.188 Inch
U-Joint Width (B):
3.625 Inch
Slip Yoke Length (C):
(Center Line to End of Spline)
5.594 Inch
Through Hole: 4.094 Inch
Barrel Diameter (D):
1.885 Inch
Spline Diameter (E):
1.378 Inch
Number of Splines (F):
32
(31 with blind spot - see note below*)
Spline Counter Bore: Yes
Counter Bore Diameter: 1.416 Inch
Counter Bore Depth: 0.390 Inch

VMRS: 024002038

 * The transmission slip yoke may have one or two missing splines inside the barrel known as blind spots. Each blind spot counts as one spline in the total spline count. The blind spots do not affect the fit of the yoke on your output shaft.

Driveshaft Slip Yoke Diagram Outside Snap Ring Style

Transmission Output Shaft Style

If your transmission has an o-ring you will need a 5.5” short barrel counter bored slip yoke.

Transmission Slip yoke with and without counter bore

Driveshaft Slip Yoke Diagram Spline Count

0


This part is compatible with:
Neapco 1-0020 Strap Kit

$71.09
