Custom Driveshafts with Slip Yoke
Action Machine offers custom driveshafts built to your exact length and balanced for a smooth ride. Each complete driveshaft includes u-joints and a slip yoke, ready for easy installation. Plus, enjoy free shipping on your order! Get a high-quality, precision-built driveshaft without the hassle. Order yours today!
|
Action Machine offers custom driveshafts for these 32 spline transmission and transfer cases: Transmissions: 4L80-E (Long Tail), 6L50, 6L80E, TH-400 (Long Tail) Transfer Case: 241C, NP136, NP208, NP246, NP261 |
Completely Customizable
- Pick your driveshaft below and tell us your custom length.
- Add any compatible differential hardware or a flange if required.
- Tell us if you need any additional modifications.
|
Order Forms: |
If you have any questions we are here to help: CHAT | PHONE(574)287-9650 | CONTACT US
(P Long) Custom Driveshafts with Slip Yoke
Custom Driveshaft & Slip Yoke - 3.5" Stl. 1350, GM 32 Spline (Long) (Sku: 3.5S1350-P(long))
Custom Driveshaft & Slip Yoke | 3.5S1350-P(long)2
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 4" Al. 3R, GM 32 Spline (Long) (Sku: 4A3R-P(long))
Custom Driveshaft & Slip Yoke | 4A3R-P(long)
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 3R
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 3R
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 5" Al. 1410, GM 32 Spline (Long) (Sku: 5A1410-P(long))
Custom Driveshaft & Slip Yoke | 5A1410-P(long)2
- Tube Dia.: 5.00" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 5.00" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 4" Stl. 1410, GM 32 Spline (Long) (Sku: 4S1410-P(long))
Custom Driveshaft & Slip Yoke | 4S1410-P(long)2
- Tube Dia.: 4.00" OD
- Length: Max 68" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 4.00" OD
- Length: Max 68" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 3.5" Stl. 1410, GM 32 Spline (Long) (Sku: 3.5S1410-P(long))
Custom Driveshaft & Slip Yoke | 3.5S1410-P(long)2
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 3" Stl. 1410, GM 32 Spline (Long) (Sku: 3S1410-P(long))
Custom Driveshaft & Slip Yoke | 3S1410-P(long)2
- Tube Dia.: 3.00" OD
- Length: Max 56" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 3.00" OD
- Length: Max 56" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1410
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 4" Stl. 1350, GM 32 Spline (Long) (Sku: 4S1350-P(long))
Custom Driveshaft & Slip Yoke | 4S1350-P(long)2
- Tube Dia.: 4.00" OD
- Length: Max 68" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 4.00" OD
- Length: Max 68" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 3" Stl. 1350, GM 32 Spline (Long) (Sku: 3S1350-P(long))
Custom Driveshaft & Slip Yoke | 3S1350-P(long)2
- Tube Dia.: 3.00" OD
- Length: Max 56" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 3.00" OD
- Length: Max 56" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 4" Al. 1350, GM 32 Spline (Long) (Sku: 4A1350-P(long))
Custom Driveshaft & Slip Yoke | 4A1350-P(long)2
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 3.5" Stl. 3R, GM 32 Spline (Long) (Sku: 3.5S3R-P(long))
Custom Driveshaft & Slip Yoke | 3.5S3R-P(long)
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 3R
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 3.50" OD
- Length: Max 61" CL-CL
- Material: Steel
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 3R
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 5" Al. 1350, GM 32 Spline (Long) (Sku: 5A1350-P(long))
Custom Driveshaft & Slip Yoke | 5A1350-P(long)2
- Tube Dia.: 5.00" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 5.00" OD
- Length: Max 85.75" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1350
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
Custom Driveshaft & Slip Yoke - 4" Al. 1330, GM 32 Spline (Long) (Sku: 4A1330-P(long))
Custom Driveshaft & Slip Yoke | 4A1330-P(long)
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1330
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
- Tube Dia.: 4.00" OD
- Length: Max 72.5" CL-CL
- Material: Aluminum
- Spline Count: 32
- Barrel Diameter: 1.875"
- Series: 1330
Transmission Model:
,
4L80E (Long)
,
6L50
,
6L80E
,
TH-400 (Long)
Transfer Case Model:
,
241C
,
NP136
,
NP208
,
NP246
,
NP261
