AMI 421-80 High Speed CV Joint

Vendor: Action Machine Inc., Sku: 421-80

Product Description

FRONT JOINT OF FRONT DRIVESHAFT - PLUNGE DESIGN - CHEVY, GMC, PONTIAC & OLDSMOBILE

Driveshaft CV Joint:

Vehicle Year
Chevrolet Astro Van (AWD) 1992-1998
Chevrolet Blazer (AWD Models) 1995-1997
GMC Jimmy (AWD) 1995-1997
GMC Safari Van (AWD) 1992-1998
Oldsmobile Bravada 1991-1997
Pontiac 6000 (AWD) 1989-1990


Specifications

HOUSING DESIGN: Crossgroove - Plunging
HOUSING OD: 3.310 Inch
NUMBER OF TEETH: 22
FLANGE DIAMETER: 4.500 Inch - Round
BOLT CIRCLE /QTY: 3.935 Inch / 4 Holes
HOLE DIAMETER: 0.410 Inch
PILOT DIAMETER: 2.874 Inch
NOTES: Pre-packed with grease and boot is crimped in place
Sku: 421-80
$105.98
