  1. Home
  2. Custom Driveshaft & Slip Yoke - 3.5" Carbon Fiber, 1350, Ford 28 Spline, 1.6" Barrel OD (Sku: 3.5C1350-G)

Custom Driveshaft & Slip Yoke - 3.5" Carbon Fiber, 1350, Ford 28 Spline, 1.6" Barrel OD (Sku: 3.5C1350-G)

Vendor: Action Machine Inc., Sku: 3.5C1350-G

Product Description

Custom Driveshaft & Slip Yoke
- Carbon Fiber, 3.5 Inch ID, 1350 Series, 28 Spline

Free Shipping on all driveshaft orders in the continental US.

This driveshaft features a carbon fiber tube, aluminum end yokes, Spicer non-greaseable u-joints, and Sonnax Slip Yoke. Every driveshaft is precision balanced and ready for install upon arrival.

Note: Flange yokes are not included. You can either send us your existing parts or add new ones to your cart before checkout (see compatible parts).

  • Product Specs
  • Critical Speed Chart
  • Compatible Parts

Specifications

Weld Yoke Material: Aluminum 6061-T6 Forged Yoke
Tube Material: 0.155 Inch Wall Seamless Carbon Fiber
Tube Diameter: 3.655 Inch Outside Diameter
3.500 Inch Inside Diameter
U-Joint: Spicer/Dana 1350 Series
Premium Non-Greasable
U-Joint Size: 1 3/16" Cap x 3 5/8" Span
(Measuring Guide - U-Joint)
Max Custom Length: Up to 68 Inches - CL to CL of U-Joint
(Measuring Guide - Driveshaft Length)
 Driveshaft length required for build.
Transmissions: G Ford / Lincoln / Mercury
AODE, 4R70,  4R70W, 4R75
Slip Yoke:  Spline Count: 28
Barrel Diameter: 1.600 Inch
Slip Yoke Length: 6.750 Inch Outside Slip Yoke

3.5 Inch Critical Speed Chart

Compatible Hardware

Compatible Yokes:
Rear Flange Yokes: 1350 Flange Yokes



Common U-Bolt & Strap Kits
U-Joint Hardware: SKU Width CL-CL:
U-Bolt Kit: 3-94-18X 1.666 Inch
Strap Kit (GM): 1-0020
 1.660 Inch
Strap Kit (Ford/Dana): 3-70-28X  1.806 Inch
Sku: 3.5C1350-G
Vendor: Action Machine Inc.

All driveshafts are custom built to your specification. Current lead time is 3 weeks from time of order.

$1,705.93
